AnyTone AT-778UV II Dual Band Mobile Radio 25W VOX with Programming

AT-778UV Mobile Radio has nice housing, stoutness & stability, advanced and reliable functions, perfect & valuable.This mobile Transceiver especially designs for drivers and it pursues philosophy of innovation and practicality.

• Dual Band/Dual Watch;
• Color LCD Display;
• Wide/Narrow Band;
• CTCSS/DCS/DTMF/2TONE/5TONE;
• ANI Function/PTT ID;
• AOP/APO Functions;
• Keypad Lock Function;
• Remote Kill/Remote Waken;

Frequency Range: VHF/UHF

Number of Channels: 200 channels

Operating Voltage: 13.8V DC ±15%

Frequency Stability: ±2.5 ppm

Operating Temperature: -20℃~+60℃

• VOX Function;
• 180 degree rotatable TFT LCD display;
• DTMF-ANI or 5Tone-ANI for automatical calling recognition;
• Built-in speaker in both Radio & Microphone; Built-in cooling fan;
• Single Call, Group Call, Selective Call and Emergency Call are all available;

Sensitivity(12dB Sinad): ≤0.25μV; ≤0.35μV

Adjacent Channel Selectivity: ≥60dB

Audio Response: +1~-3dB (0.3~3KHz); +1~-3dB (0.3~2.55KHz)

Hum & Noise: ≥45dB; ≥40dB

Audio Distortion: ≤5%

Audio Power Output: >2W@8

Power Output: 25W/15W/5W (Wide/Narrow Band)

Adjacent Channel Power: ≥70dB ;≥60dB

Hum & Noise: ≥40dB; ≥36dB

Spurious Emission: ≥60dB

Audio Response: +1~-3dB (0.3~3KHz); +1~-3dB (0.3~2.55KHz

Audio Distortion: ≤5%

• (Number 1) Power On/ Off/ Mute
• (Number 2-7) Self Define Key
• (Number 8) Function Key/ Function Group Key
• (Number 9) Microphone Jack
• (Number 10) Channel Switch/ Push Button/ Key Lock
• (Number 11) LCD Display

• (Number 1) Antenna Connector
• (Number 2) Ex-Speaker Jack
• (Number 3) Power Cable

• (Number 1) TX/RX Indicator: Light green while receiving; Light red while transmitting;
• (Number 2) A/B Band: Choose left band or right band as main band;
• (Number 3) MIC: Speak here during transmission;
• (Number 4) Number Key: Input VFO frequency or DTMF dial out etc;
• (Number 5) Band Indicator: The indicator light on for main band;
• (Number 6) Speaker: when shut the speaker in the base, you can hear the calling by this speaker;
